Silicone rubber control cable

  • Silicone rubber high temperature control cable
Silicone rubber high temperature control cable

Silicone rubber high temperature control cable

  • Silicone rubber high temperature control cable
  • Silicone rubber control cable
  • Product description: Silicone rubber high temperature control cable is suitable for connecting or signal transmission of mobile or fixed laying electrical instrument with AC rated voltage of 450/750V and below.
  • INQUIRY
Silicone rubber high temperature control cable is suitable for connecting or signal transmission of mobile or fixed laying electrical instrument with AC rated voltage of 450/750V and below. The Silicone rubber cable has good thermal stability and can maintain good electrical performance and softness in high temperature, low temperature and corrosiveness. Sex, suitable for metallurgy, electric power, petrochemical and other industries with special requirements such as mobile temperature resistance.
Silicone rubber high temperature control cable Use characteristics:
1. AC rated voltage: U0/U 450/750KV, maximum operating temperature: 180°C
2. Minimum ambient temperature: silicone rubber sheath: fixed laying -60 ° C, non-fixed laying -20 ° C
3. The cable installation temperature should not be lower than -20 °C.
4. Cable allowable bending radius: non-armored cable is at least 6 times the outer diameter of the cable

Silicone rubber high temperature control cable Basic model and name:

KGG

Silicone rubber insulated and sheathed control cable

KGGR

Silicone rubber insulation and sheath control flexible cable

KGGP

Silicone rubber insulated and sheathed copper wire braided shielded control cable

KGGRP

Silicone rubber insulated and sheathed copper wire braided shield control flexible cable

KGGRP1

Silicone rubber insulated and sheathed tin-plated braided shielded control flexible cable

1, if you need flame retardant silicone rubber cable, add ZR before the model number;
2. The copper wire in the conductor core can be tinned.

Refer to this document for Silicone rubber high temperature control cable size parameters.Silicone Rubber High Temperature Resistant Control Cable
