  • Product description: Silicone Rubber electrical Flat Cable is used as power connection & controlling & signal& lighting of various moving power equipment, in the field of lifting, transportation, machine, electronic, stee
  • INQUIRY

Silicone Rubber electrical Flat Cable is used as power connection & controlling & signal& lighting of various moving power equipment, in the field of lifting, transportation, machine, electronic, steel, medicine, metallurgy, port, mine and storage etc.

Performance for Usage
1: Rated voltage UO/U:0.6/1kV
2: Wor k ing temperature allowed by cable:
-60℃~+180℃ for cable with silicon rubber insulation;
-60℃~+200℃ for cable with fluoroplastics insulation
3: Max temperature of cable conductor is no more than 250℃ during short circuit(the longest lasting time is no more than 5s).
4: Temperature for installing is no lower than -20℃.
5: Min. bending radius of cable is 10 times that of small border length of cable.
Type and description of cable listed in table 1

Silicone Rubber electrical Flat Cable
The figure of cable structure
Rubber electrical Flat Cable

Main Performance Parameter
DC resistance of conductor at 20shall meet the requirements of the following table:
Silicone Rubber cable

Specification and data for reference stipulated in the following table:
silicone flat wire

Insulated Resistance of Finished Cable Conductor
Insulated resistance of finished cable insulated conductor will be no less than 50MΩ for cable with conductive core cross section 50mm2 or lower and 35 MΩ for cable with conductive core cross section 70~185mm2 under the condition that cable length is 1km and temperature is 20℃. Finished cable with multi-core shall bear voltage test of 3500v, AC 50Hz for 5 minutes without puncture of insulation.

We can customize all kinds of silicone rubber flat cables. We welcome drawings and we can process them according to the drawings.
